Access Point HPE Networking AP-514 (US)

Sobre este producto

• 📶 Wi-Fi 6 (802.11ax) en bandas 2.4 GHz y 5 GHz
• 🏢 Serie 510 Campus diseñada para entornos de alta densidad de dispositivos móviles e IoT
• 🔀 Sirve simultáneamente a múltiples clientes y tipos de tráfico con eficiencia
• 📈 Mayores tasas de datos tanto por dispositivo como del sistema completo
• 🔧 Formato in-ceiling para montaje en techo

Característica	Detalle
Marca	HPE
Línea de producto	HPE Aruba
Modelo	AP-514 (US)
Edition	Campus
Fabricante	Aruba
Unidad óptica	None
Estándares	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, Wi-Fi CERTIFIED
Connectivity Technology	Wireless
Protocolos de enlace	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Características	4x4 MU-MIMO technology, Adaptive Radio Management (ARM), Advanced Cellular Coexistence (ACC), Air Monitor (AM), AppRF technology, Aruba AirMatch, Auto-uplink (auto MDI/MDI-X), ClientMatch, Cyclic Delay Diversity (CDD), Cyclic shift diversity (CSD), DFS support, Enhanced ClientMatch, Intelligent Power Monitoring (IPM), Link Aggregation Control Protocol (LACP), Low Density Parity Check (LDPC), Maximum Ratio Combining (MRC), MDI/MDI-X switch, MU-MIMO technology, Packet aggregation A-MPDU, Packet aggregation A-MSDU, Quality of Service (QoS), Reset button, Secure Core Technology (SCT), SecureJack, Security lock slot (cable lock sold separately), Space Time Blocking Code (STBC), Space-Time Block Code, Spectrum analyzer, Target Wait Time (TWT), Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM), Wireless intrusion protection
Factor de forma	In-ceiling
Network Band	2.4 GHz, 5 GHz
Power Over Ethernet (PoE)	PoE
Tipo de producto	Wireless access point
Spread Spectrum Method	DSSS, OFDM
Status Indicators	Status, System
Wireless LAN	802.11a/b/g/n/ac
Interfaces	1 x 1000Base-T (PoE+) - RJ-45, 1 x HPE Smart Rate - RJ-45, 1 x serial / console - micro-USB, 1 x USB 2.0 - Type A, 4 x antenna - RP-SMA
Power Consumption Operational	20.8 watt
Antenna Form Factor	External
Antennas	4
Directivity	Omni-directional
Line Coding Format	1024 QAM, 16 QAM, 256 QAM, 64 QAM, BPSK, CCK, OFDM, QPSK
Temp. máx. de operación	122 degree Fahrenheit
Temp. mín. de operación	32 degree Fahrenheit
MTBF	560,000 Year
Humedad de operación	5 - 93% (non-condensing)
Operating System Required	ArubaOS, InstantOS
Capacity	BSSIDs per radio: 16, Wireless clients per Wi-Fi radio: 256
Cantidad por empaque	1
Ruggedized Design	Indoor
Service Activation	No
Network Device	Maximum data rate (2.4 GHz): 575 Mbps, Maximum data rate (5 GHz): 4.8 Gbps, Peak data rate: 5.4 Gbps
Alto	1.8 inch
Weight	28.57 ounce
Ancho	7.9 inch
Profundidad	7.9 inch
Color	White
Certificado ENERGY STAR	No
Cumple EPEAT	No
TCO Certified	No
