Access Point Aruba HPE Networking AP-505 (US)

Sobre este producto

• 📶 Wi-Fi 6: doble banda 2.4/5 GHz con velocidad de hasta 1.49 Gbps.
• 📡 OFDMA y MU-MIMO: reparten ancho de banda y airtime entre múltiples clientes Wi-Fi 6 simultáneos.
• 🛡️ Seguridad WPA3 y Enhanced Open, además de WPA2-MPSK para conectar sin cambiar la contraseña.
• 🔵 Bluetooth 5.0 y Zigbee-ready: plataforma IoT para sensores, localización y asset-tracking.
• ⚡ Aruba Air Slice: asignación dinámica de ancho de banda para clientes Wi-Fi 6 y no Wi-Fi 6.
• 🔧 Incluye bracket de montaje; ideal para pymes, retail y centros educativos.

Característica	Detalle
Marca	Aruba
Línea de producto	HPE Aruba
Modelo	AP-505 (US)
Edition	Campus
Fabricante	Aruba
Unidad óptica	None
Estándares	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, Wi-Fi CERTIFIED 6
Connectivity Technology	Wireless
Protocolos de enlace	Bluetooth 5.0, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Data Transfer Rate	1.2 GBps
Características	2x2 MIMO technology, Advanced Cellular Coexistence (ACC), Auto-uplink (auto MDI/MDI-X), ClientMatch, Cyclic Delay Diversity (CDD), Cyclic shift diversity (CSD), Deep Packet Inspection (DPI), Direct Sequence Spread Spectrum (DSSS), Dynamic Frequency Selection (DFS), Energy-Efficient Ethernet (EEE), High Efficiency (HE) support, High-Throughput (HT) support, Intelligent Power Monitoring (IPM), LED off mode, Low Density Parity Check (LDPC), Maximum Ratio Combining (MRC), MU-MIMO technology, Orthogonal Frequency Division Multiple Access (OFDMA), Orthogonal Frequency Division Multiplexing (OFDM), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Security slot (Kensington security lock compatible), SU-MIMO technology, Target Wait Time (TWT), Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM), Very High Throughput (VHT) support
Factor de forma	In-ceiling
Network Band	2.4 GHz, 5 GHz
Power Over Ethernet (PoE)	PoE
Tipo de producto	Wireless access point
Spread Spectrum Method	DSSS, OFDM, OFDMA
Status Indicators	Status, System
Wireless LAN	802.11a/b/g/n/ac/ax, Bluetooth 5.0
Interfaces	1 x 1000Base-T - RJ-45, 1 x console - micro-USB, 1 x USB 2.0 - Type A
Power Consumption Operational	8.9 watt
Antenna Form Factor	Internal
Antenna Gain Level	5.7 DBi
Antennas	2
Directivity	Omni-directional
Encryption	SSL, WPA, WPA2, WPA3
Internet of Things (IoT) Compatible	Yes
Line Coding Format	1024 QAM, 16 QAM, 256 QAM, 64 QAM, BPSK, CCK, OFDM, OFDMA, QPSK
Temp. máx. de operación	122 degree Fahrenheit
Temp. mín. de operación	32 degree Fahrenheit
MTBF	148 Year
Humedad de operación	5 - 93% (non-condensing)
Operating System Required	ArubaOS, InstantOS
Capacity	BSSIDs per radio: 16, OFDMA units: 8, Wireless clients per Wi-Fi radio: 256
IoT Communications Technology	Bluetooth Low Energy (LE), Zigbee
Cantidad por empaque	1
Ruggedized Design	Indoor
Service Activation	No
Network Device	Aggregate throughput: 1.774 Gbps, Maximum data rate (2.4 GHz): 574 Mbps, Maximum data rate (5 GHz): 1.2 Gbps
Accesorios incluidos	Mounting bracket
Color	White
Certificado ENERGY STAR	No
Cumple EPEAT	No
TCO Certified	No
